ADA2088 · Adafruit
Adafruit product #2088.
| Part number | ADA2088 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › TFT LCD |
| Pins | 11 |
Adafruit 1.44" Color TFT LCD Display with MicroSD Card breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VIN | power | |
| 2 | +3V3 | power | |
| 3 | GND | ground | |
| 4 | SCK | bidirectional | |
| 5 | MISO | bidirectional | |
| 6 | MOSI | bidirectional | |
| 7 | TFTCS | bidirectional | |
| 8 | RESET | bidirectional | |
| 9 | TFTDC | bidirectional | |
| 10 | CARDCS | bidirectional | |
| 11 | LITE | bidirectional |
