ADA5393 · Adafruit
Adafruit product #5393.
| Part number | ADA5393 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › TFT LCD |
| Pins | 11 |
Adafruit 1.47" 320x172 Round Rectangle Color IPS TFT Display pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VIN | power | |
| 2 | +3V3 | power | |
| 3 | GND | ground | |
| 4 | SCK | bidirectional | |
| 5 | MISO | bidirectional | |
| 6 | MOSI | bidirectional | |
| 7 | TFTCS | bidirectional | |
| 8 | TFTRST | bidirectional | |
| 9 | TFTDC | bidirectional | |
| 10 | CARDCS | bidirectional | |
| 11 | LITE | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit 1.47in 320x172 Round Rectangle TFT (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
| Supplier | Stock | Price | Status | |
|---|---|---|---|---|
| Mouser | 4 | $17.50 (1+) | View |
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
