ADA6366 · AdafruitActive
Adafruit product #6366.
| Part number | ADA6366 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › E-Paper |
| Pins | 13 |
Adafruit 2.13" 250x122 Quad-Color eInk / ePaper Display w/ SRAM pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VIN | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCLK | bidirectional | |
| 5 | MISO | bidirectional | |
| 6 | MOSI | bidirectional | |
| 7 | DISPCS | bidirectional | |
| 8 | DC | bidirectional | |
| 9 | SRAMCS | bidirectional | |
| 10 | SDCS | bidirectional | |
| 11 | RESET | bidirectional | |
| 12 | BUSY | bidirectional | |
| 13 | ENABLE | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit 2.13in eInk Breakout Rev D (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
| Supplier | Stock | Price | Status | |
|---|---|---|---|---|
| Mouser | 0 | $19.95 (1+) | New at Mouser | View |
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
