ADA4224 · Adafruit
Adafruit product #4224.
| Part number | ADA4224 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › E-Paper |
| Pins | 12 |
Adafruit eInk Breakout Friend with 32KB SRAM pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VIN | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCLK | bidirectional | |
| 5 | MISO | bidirectional | |
| 6 | MOSI | bidirectional | |
| 7 | DISPCS | bidirectional | |
| 8 | DC | bidirectional | |
| 9 | SRAMCS | bidirectional | |
| 10 | RESET | bidirectional | |
| 11 | BUSY | bidirectional | |
| 12 | ENABLE | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit eInk Breakout Friend (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
