ADA4800 · Adafruit
Adafruit product #4800.
| Part number | ADA4800 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › E-Paper |
| Pins | 2 |
Adafruit MagTag - 2.9" Grayscale E-Ink WiFi Display pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | RXD0 | bidirectional | |
| 2 | TXD0 | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit MagTag (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
