Name: Adafruit 3.5" TFT 320x480 with Capacitive Touch Breakout Board
Brand: Adafruit

Parts › Displays & LEDs › TFT LCD

ADA5846 · AdafruitObsolete

Adafruit 3.5" TFT 320x480 with Capacitive Touch Breakout Board photo

Adafruit 3.5" TFT 320x480 with Capacitive Touch Breakout Board illustration

Adafruit product #5846.

Part number	ADA5846
Manufacturer	Adafruit
Category	Displays & LEDs › TFT LCD
Pins	40

Adafruit 3.5" TFT 320x480 with Capacitive Touch Breakout Board pinout

Pin	Name	Type
1	GND	ground
2	+5V	power
3	LCD_CS_5V	bidirectional
4	LCD_RS_5V	bidirectional
5	LCD_WR_5V	bidirectional
6	LCD_RD_5V	bidirectional
7	LCD_RST_5V	bidirectional
8	LCD_LITE	bidirectional
9	CTP_IRQ	bidirectional
10	CTP_SCL_5V	bidirectional
11	CTP_SDA_5V	bidirectional
12	GND	ground
13	LCD_DATA0_5V	bidirectional
14	LCD_DATA1_5V	bidirectional
15	LCD_DATA2_5V	bidirectional
16	LCD_DATA3_5V	bidirectional
17	LCD_DATA4_5V	bidirectional
18	LCD_DATA5_5V	bidirectional
19	LCD_DATA6_5V	bidirectional
20	LCD_DATA7_5V	bidirectional
21	GND	ground
22	+5V	power
23	VCC	power
24	LCD_WR_5V	bidirectional
25	SDO	bidirectional
26	SDI_5V	bidirectional
27	LCD_CS_5V	bidirectional
28	LCD_RS_5V	bidirectional
29	LCD_RST_5V	bidirectional
30	LCD_LITE	bidirectional
31	GND	ground
32	CTP_IRQ	bidirectional
33	CTP_SDA_5V	bidirectional
34	CTP_SCL_5V	bidirectional
35	GND	ground
36	IM2	bidirectional
37	IM1	bidirectional
38	IM0	bidirectional
39	SD_CS_5V	bidirectional
40	CARDDET	bidirectional

Schematic symbol and footprint

Schematic symbol

Footprint: Adafruit 3.5 inch 480x320 Capacitive Touch Display (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
