ADA4285 · AdafruitActive
Adafruit product #4285 — built on ESP32.
| Part number | ADA4285 |
|---|---|
| Manufacturer | Adafruit |
| Category | Communication & Wireless › Wi-Fi |
| Pins | 80 |
Adafruit AirLift Shield - ESP32 WiFi Co-Processor pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SCL | bidirectional | |
| 2 | SDA | bidirectional | |
| 3 | AREF | bidirectional | |
| 4 | GND | ground | |
| 5 | D13 | bidirectional | |
| 6 | D12 | bidirectional | |
| 7 | D11 | bidirectional | |
| 8 | D10 | bidirectional | |
| 9 | D9 | bidirectional | |
| 10 | D8 | bidirectional | |
| 11 | D7 | bidirectional | |
| 12 | D6 | bidirectional | |
| 13 | D5 | bidirectional | |
| 14 | D4 | bidirectional | |
| 15 | D3 | bidirectional | |
| 16 | D2 | bidirectional | |
| 17 | D1 | bidirectional | |
| 18 | D0 | bidirectional | |
| 19 | SCL | bidirectional | |
| 20 | SDA | bidirectional | |
| 21 | AREF | bidirectional | |
| 22 | GND | ground | |
| 23 | D13 | bidirectional | |
| 24 | D12 | bidirectional | |
| 25 | D11 | bidirectional | |
| 26 | D10 | bidirectional | |
| 27 | D9 | bidirectional | |
| 28 | D8 | bidirectional | |
| 29 | D7 | bidirectional | |
| 30 | D6 | bidirectional | |
| 31 | D5 | bidirectional | |
| 32 | D4 | bidirectional | |
| 33 | D3 | bidirectional | |
| 34 | D2 | bidirectional | |
| 35 | D1 | bidirectional | |
| 36 | D0 | bidirectional | |
| 37 | SCK | bidirectional | |
| 38 | MISO | bidirectional | |
| 39 | MOSI | bidirectional | |
| 40 | ESP32_CS | bidirectional | |
| 41 | ESP32_BUSY | bidirectional | |
| 42 | GPIO0 | bidirectional | |
| 43 | ESP32_RESET | bidirectional | |
| 44 | SDCS | bidirectional | |
| 45 | ESP_RX | bidirectional | |
| 46 | ESP_TX | bidirectional | |
| 47 | MISO_ICSP | bidirectional | |
| 48 | 5V_ICSP | bidirectional | |
| 49 | SCK_ICSP | bidirectional | |
| 50 | MOSI_ICSP | bidirectional | |
| 51 | RESET_ICSP | bidirectional | |
| 52 | GND | ground | |
| 53 | NC | bidirectional | |
| 54 | VIOREF | bidirectional | |
| 55 | RESET | bidirectional | |
| 56 | +3V | power | |
| 57 | +5V | power | |
| 58 | GND | ground | |
| 59 | GND | ground | |
| 60 | VIN | power | |
| 61 | A0 | bidirectional | |
| 62 | A1 | bidirectional | |
| 63 | A2 | bidirectional | |
| 64 | A3 | bidirectional | |
| 65 | A4 | bidirectional | |
| 66 | A5 | bidirectional | |
| 67 | NC | bidirectional | |
| 68 | VIOREF | bidirectional | |
| 69 | RESET | bidirectional | |
| 70 | +3V | power | |
| 71 | +5V | power | |
| 72 | GND@2 | bidirectional | |
| 73 | GND | ground | |
| 74 | VIN | power | |
| 75 | A0 | bidirectional | |
| 76 | A1 | bidirectional | |
| 77 | A2 | bidirectional | |
| 78 | A3 | bidirectional | |
| 79 | A4 | bidirectional | |
| 80 | A5 | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit Airlift Shield (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
