ADA3060 · AdafruitActive
Adafruit product #3060 — built on ATWINC1500. Interfaces: I2C.
| Part number | ADA3060 |
|---|---|
| Manufacturer | Adafruit |
| Category | Communication & Wireless › Wi-Fi |
| Pins | 13 |
| Frequency | 2.4 GHz |
| Voltage (max) | 3.6 V |
| Voltage (min) | 2.7 V |
Adafruit ATWINC1500 WiFi Breakout with uFL Connector pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | +5V | power | |
| 2 | GND | ground | |
| 3 | SCK | bidirectional | |
| 4 | MISO | bidirectional | |
| 5 | MOSI | bidirectional | |
| 6 | CS | bidirectional | |
| 7 | EN | bidirectional | |
| 8 | IRQ | bidirectional | |
| 9 | RST | bidirectional | |
| 10 | WAKE | bidirectional | |
| 11 | CFG | bidirectional | |
| 12 | RXD | bidirectional | |
| 13 | TXD | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit WINC1500 (uFL Antenna) Breakout (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
