ADA4479 · Adafruit
Adafruit product #4479 — built on LIS3MDL.
| Part number | ADA4479 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › IMU, Accelerometers & Gyros |
| Pins | 10 |
Adafruit Triple-axis Magnetometer - LIS3MDL pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | DRDY | bidirectional | |
| 3 | SDO | bidirectional | |
| 4 | CS_5V | bidirectional | |
| 5 | VCC | power | |
| 6 | 3.3V | power | |
| 7 | GND | ground | |
| 8 | SCL | bidirectional | |
| 9 | SDA | bidirectional | |
| 10 | INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit LIS3MDL Triple-axis Magnetometer (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
