ADA4503 · AdafruitActive
Adafruit product #4503 — built on LSM6DS3TR-C.
| Part number | ADA4503 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › IMU, Accelerometers & Gyros |
| Pins | 12 |
Adafruit LSM6DS3TR-C 6-DoF Accel + Gyro IMU pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SCX | bidirectional | |
| 2 | SDX | bidirectional | |
| 3 | GND | ground | |
| 4 | VCC | power | |
| 5 | 3.3V | power | |
| 6 | GND | ground | |
| 7 | SCL | bidirectional | |
| 8 | SDA | bidirectional | |
| 9 | SDO | bidirectional | |
| 10 | CS_5V | bidirectional | |
| 11 | INT1 | bidirectional | |
| 12 | INT2 | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit LSM6DS3TR-C (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
