ADA4438 · AdafruitActive
Adafruit product #4438 — built on LSM6DSOX.
| Part number | ADA4438 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › IMU, Accelerometers & Gyros |
| Pins | 14 |
Adafruit LSM6DSOX 6 DoF Accelerometer and Gyroscope pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SCX | bidirectional | |
| 2 | SDX | bidirectional | |
| 3 | OCS_AUX | bidirectional | |
| 4 | SDO_AUX | bidirectional | |
| 5 | GND | ground | |
| 6 | VCC | power | |
| 7 | 3.3V | power | |
| 8 | GND | ground | |
| 9 | SCL | bidirectional | |
| 10 | SDA | bidirectional | |
| 11 | SDO | bidirectional | |
| 12 | CS_5V | bidirectional | |
| 13 | INT1 | bidirectional | |
| 14 | INT2 | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit_LSM6DSOX (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
