ADA5914 · AdafruitActive
Adafruit product #5914 — built on LTC4316. Interfaces: I2C.
| Part number | ADA5914 |
|---|---|
| Manufacturer | Adafruit |
| Category | Interface & Expansion › Level Shifters |
| Pins | 10 |
Adafruit LTC4316 I2C Address Translator pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | XORL | bidirectional | |
| 3 | VCC | power | |
| 4 | GND | ground | |
| 5 | SCL_IN | bidirectional | |
| 6 | SDA_IN | bidirectional | |
| 7 | SCL_OUT | bidirectional | |
| 8 | SDA_OUT | bidirectional | |
| 9 | READY | bidirectional | |
| 10 | ENABLE | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit LTC4316 I2C Address Translator - Stemma QT / Qwiic (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
