ADA1875 · AdafruitActive
Adafruit product #1875 — built on TXB0104.
| Part number | ADA1875 |
|---|---|
| Manufacturer | Adafruit |
| Category | Interface & Expansion › Level Shifters |
| Pins | 12 |
TXB0104 Bi-Directional Level Shifter pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | LV | bidirectional | |
| 2 | HV | bidirectional | |
| 3 | A1 | bidirectional | |
| 4 | B1 | bidirectional | |
| 5 | A2 | bidirectional | |
| 6 | B2 | bidirectional | |
| 7 | A3 | bidirectional | |
| 8 | B3 | bidirectional | |
| 9 | A4 | bidirectional | |
| 10 | B4 | bidirectional | |
| 11 | OE | bidirectional | |
| 12 | GND | ground |
Schematic symbol and footprint
Footprint: TXB0104 4-channel Bi-Directional Level Shifter (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
