ADA3886 · Adafruit
Adafruit product #3886 — built on MPU-6050. Interfaces: I2C.
| Part number | ADA3886 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › IMU, Accelerometers & Gyros |
| Pins | 12 |
Adafruit MPU-6050 6-DoF Accel and Gyro Sensor - STEMMA QT Qwiic pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | AD0 | bidirectional | |
| 2 | FSYNC_IN | bidirectional | |
| 3 | SCL_EXT | bidirectional | |
| 4 | SDA_EXT | bidirectional | |
| 5 | CLKIN | bidirectional | |
| 6 | GND | ground | |
| 7 | VCC | power | |
| 8 | 3.3V | power | |
| 9 | GND | ground | |
| 10 | SCL | bidirectional | |
| 11 | SDA | bidirectional | |
| 12 | INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit MPU6050 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
