ADA6489 · AdafruitActive
Adafruit product #6489 — built on TMAG5273.
| Part number | ADA6489 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › IMU, Accelerometers & Gyros |
| Pins | 6 |
Adafruit TMAG5273 (A1) 3D Hall Effect Magnetometer Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCL | bidirectional | |
| 5 | SDA | bidirectional | |
| 6 | !INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit TMAG5273 3D Hall Effect Magnetometer Breakout (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
| Supplier | Stock | Price | Status | |
|---|---|---|---|---|
| DigiKey | 42 | $5.95 (1+) | Active | View |
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
