BOB-12052 · SparkFunActive
(SparkFun BOB-12052)
| Part number | BOB-12052 |
|---|---|
| Manufacturer | SparkFun |
| Category | Power › Battery Charging & Management |
| Pins | 10 |
SparkFun Coulomb Counter Breakout - LTC4150 pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | IN | bidirectional | |
| 2 | GND | ground | |
| 3 | GND | ground | |
| 4 | OUT | bidirectional | |
| 5 | !SHDN! | bidirectional | |
| 6 | !CLR! | bidirectional | |
| 7 | GND | ground | |
| 8 | POL | bidirectional | |
| 9 | !INT! | bidirectional | |
| 10 | VIO | power |
Schematic symbol and footprint
Footprint: SparkFun Coulomb Counter Breakout - LTC4150 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
