ADA3538 · Adafruit
Adafruit product #3538 — built on AMG8833.
| Part number | ADA3538 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature |
| Pins | 6 |
Adafruit AMG8833 IR Thermal Camera Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCL | bidirectional | |
| 5 | SDA | bidirectional | |
| 6 | INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit AMG8833 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
