ADA4407 · Adafruit
Adafruit product #4407 — built on MLX90640.
| Part number | ADA4407 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature |
| Pins | 5 |
Adafruit MLX90640 IR Thermal Camera Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SDA | bidirectional | |
| 2 | SCL | bidirectional | |
| 3 | GND | ground | |
| 4 | 3.3V | power | |
| 5 | VCC | power |
Schematic symbol and footprint
Footprint: Adafruit MLX90640 Thermal Camera (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
