ADA3328 · Adafruit
Adafruit product #3328 — built on PT100, MAX31865.
| Part number | ADA3328 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature |
| Pins | 12 |
Adafruit PT100 RTD Temperature Sensor Amplifier - MAX31865 pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | FORCE- | bidirectional | |
| 2 | RTDIN- | bidirectional | |
| 3 | RTDIN+ | bidirectional | |
| 4 | FORCE+ | bidirectional | |
| 5 | VIN | power | |
| 6 | GND | ground | |
| 7 | 3.3V | power | |
| 8 | SCLK | bidirectional | |
| 9 | SDO | bidirectional | |
| 10 | SDI | bidirectional | |
| 11 | CS | bidirectional | |
| 12 | DRDY | bidirectional |
Schematic symbol and footprint
Schematic symbol
Footprint: Adafruit MAX31865 RTD Sensor Breakout (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
