ADA4369 · Adafruit
Adafruit product #4369 — built on PCT2075. Interfaces: I2C.
| Part number | ADA4369 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature |
| Pins | 8 |
Adafruit PCT2075 Temperature Sensor - STEMMA QT / Qwiic pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | A0 | bidirectional | |
| 2 | A1 | bidirectional | |
| 3 | A2 | bidirectional | |
| 4 | VCC | power | |
| 5 | GND | ground | |
| 6 | SCL | bidirectional | |
| 7 | SDA | bidirectional | |
| 8 | INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit PCT2075 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
