ADA3660 · Adafruit
Adafruit product #3660 — built on BME680.
| Part number | ADA3660 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Gas & Air Quality |
| Pins | 7 |
Adafruit BME680 - Temperature, Humidity, Pressure and Gas Sensor pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCK/SCL | bidirectional | |
| 5 | SDO/ADR | bidirectional | |
| 6 | SDI/SDA | bidirectional | |
| 7 | CS | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit BME680 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
