ADA4632 · Adafruit
Adafruit product #4632 — built on PMSA003I.
| Part number | ADA4632 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Gas & Air Quality |
| Pins | 7 |
Adafruit PMSA003I Air Quality Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCL | bidirectional | |
| 5 | SDA | bidirectional | |
| 6 | RESET | bidirectional | |
| 7 | SET | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit PMSA003I Air Quality Breakout (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
