ADA3709 · Adafruit
Adafruit product #3709 — built on SGP30, ECO2.
| Part number | ADA3709 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Gas & Air Quality |
| Pins | 5 |
Adafruit SGP30 Air Quality Sensor Breakout - VOC and eCO2 pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCL | bidirectional | |
| 5 | SDA | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit SGP30 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
