ADA4867 · Adafruit
Adafruit product #4867 — built on SCD-30, CO2.
| Part number | ADA4867 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Gas & Air Quality |
| Pins | 6 |
Adafruit SCD-30 - NDIR True CO2 Temperature and Humidity Sensor pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | RDY | bidirectional | |
| 2 | SDA | bidirectional | |
| 3 | SCL | bidirectional | |
| 4 | GND | ground | |
| 5 | 3.3V | power | |
| 6 | VCC | power |
Schematic symbol and footprint
Footprint: Adafruit SCD30 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
