ADA5606 · Adafruit
Adafruit product #5606 — built on ENS160, CCS811.
| Part number | ADA5606 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Gas & Air Quality |
| Pins | 8 |
Adafruit ENS160 MOX Gas Sensor - Sciosense CCS811 Upgrade pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | 3.3V | power | |
| 3 | GND | ground | |
| 4 | SCL/SCK | bidirectional | |
| 5 | SDO/ADR | bidirectional | |
| 6 | SDA/MOSI | bidirectional | |
| 7 | !CS | bidirectional | |
| 8 | !INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit ENS160 MOX Gas Sensor - Sciosense CCS811 Upgrade - STEMMA QT / Qwiic (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
