ADA5976 · AdafruitActive
Adafruit product #5976 — built on DS2484. Interfaces: I2C.
| Part number | ADA5976 |
|---|---|
| Manufacturer | Adafruit |
| Category | Interface & Expansion › Breakouts & Adapters |
| Pins | 9 |
Adafruit DS2484 I2C to 1-Wire Bus Adapter Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | GND | ground | |
| 2 | 1WIRE | bidirectional | |
| 3 | VCCIO | bidirectional | |
| 4 | VCC | power | |
| 5 | GND | ground | |
| 6 | SCL | bidirectional | |
| 7 | SDA | bidirectional | |
| 8 | 1WIRE | bidirectional | |
| 9 | SLPZ | bidirectional |
Schematic symbol and footprint
Schematic symbol
Footprint: Adafruit DS2484 I2C to 1-Wire Breakout (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
