ADA5625 · AdafruitActive
Adafruit product #5625. Interfaces: I2C.
| Part number | ADA5625 |
|---|---|
| Manufacturer | Adafruit |
| Category | Interface & Expansion › Breakouts & Adapters |
| Pins | 8 |
Adafruit Qwiic / Stemma QT 5 Port Hub pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SDA | bidirectional | |
| 2 | SCL | bidirectional | |
| 3 | GND | ground | |
| 4 | VCC | power | |
| 5 | VCC | power | |
| 6 | GND | ground | |
| 7 | SCL | bidirectional | |
| 8 | SDA | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit Qwiic / Stemma QT 5 Port Hub (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
