ADA5165 · AdafruitActive
Adafruit product #5165 — built on MCP9601, MCP96L01. Interfaces: I2C.
| Part number | ADA5165 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature |
| Pins | 11 |
Adafruit MCP9601 (MCP96L01) I2C Thermocouple Amplifier pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | - | bidirectional | |
| 2 | + | bidirectional | |
| 3 | VIN | power | |
| 4 | GND | ground | |
| 5 | SCL | bidirectional | |
| 6 | SDA | bidirectional | |
| 7 | ALERT1 | bidirectional | |
| 8 | ALERT2 | bidirectional | |
| 9 | ALERT3 | bidirectional | |
| 10 | ALERT4 | bidirectional | |
| 11 | ADDR | bidirectional |
Schematic symbol and footprint
Schematic symbol
Footprint: Adafruit MCP9601 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
