ADA5027 · AdafruitActive
Adafruit product #5027 — built on MCP9808. Interfaces: I2C.
| Part number | ADA5027 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature |
| Pins | 6 |
Adafruit MCP9808 High Accuracy I2C Temperature Sensor Breakout pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | VCC | power | |
| 2 | GND | ground | |
| 3 | SCL | bidirectional | |
| 4 | SDA | bidirectional | |
| 5 | ALERT | bidirectional | |
| 6 | A0 | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit MCP9808 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
