ADA4022 · AdafruitActive
Adafruit product #4022 — built on MLX90393.
| Part number | ADA4022 |
|---|---|
| Manufacturer | Adafruit |
| Category | Sensors › Temperature |
| Pins | 12 |
Adafruit Wide-Range Triple-axis Magnetometer - MLX90393 pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | A0_3V | bidirectional | |
| 2 | A1_3V | bidirectional | |
| 3 | SENB | bidirectional | |
| 4 | INT/TRIG_3V | bidirectional | |
| 5 | MISO_3V | bidirectional | |
| 6 | GND | ground | |
| 7 | VCC | power | |
| 8 | 3.3V | power | |
| 9 | GND | ground | |
| 10 | SCL | bidirectional | |
| 11 | SDA | bidirectional | |
| 12 | INT_3V | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit MLX90393 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
