ADA4984 · Adafruit
Adafruit product #4984.
| Part number | ADA4984 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › Display Modules & Monitors |
| Pins | 14 |
Adafruit DVI Breakout Board - For HDMI Source Devices pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | SCL | bidirectional | |
| 2 | SDA | bidirectional | |
| 3 | 5.0V | bidirectional | |
| 4 | TX2+ | bidirectional | |
| 5 | TX2- | bidirectional | |
| 6 | GND | ground | |
| 7 | TX1+ | bidirectional | |
| 8 | TX1- | bidirectional | |
| 9 | GND | ground | |
| 10 | TX0+ | bidirectional | |
| 11 | TX0- | bidirectional | |
| 12 | GND | ground | |
| 13 | TXC+ | bidirectional | |
| 14 | TXC- | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit DVI Breakout (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Where to buy
| Supplier | Stock | Price | Status | |
|---|---|---|---|---|
| Mouser | 29 | $1.95 (1+) | View |
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
