ADA5957 · Adafruit
Adafruit product #5957.
| Part number | ADA5957 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › Display Modules & Monitors |
| Pins | 15 |
Adafruit DVI Sock for Pico - Works with HDMI Displays pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | D1N | bidirectional | |
| 2 | D1P | bidirectional | |
| 3 | GND | ground | |
| 4 | D2N | bidirectional | |
| 5 | D2P | bidirectional | |
| 6 | HPD | bidirectional | |
| 7 | CEC | bidirectional | |
| 8 | D0P | bidirectional | |
| 9 | D0N | bidirectional | |
| 10 | GND | ground | |
| 11 | CKP | bidirectional | |
| 12 | CKN | bidirectional | |
| 13 | GND | ground | |
| 14 | +5V | power | |
| 15 | UTIL | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit DVI Sock for Pico (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
