ADA5423 · Adafruit
Adafruit product #5423 — built on TSC2007. Interfaces: I2C.
| Part number | ADA5423 |
|---|---|
| Manufacturer | Adafruit |
| Category | Displays & LEDs › Display Modules & Monitors |
| Pins | 10 |
Adafruit TSC2007 I2C Resistive Touch Screen Controller pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | Y- | bidirectional | |
| 2 | X- | bidirectional | |
| 3 | Y+ | bidirectional | |
| 4 | X+ | bidirectional | |
| 5 | VCC | power | |
| 6 | 3.3V | power | |
| 7 | GND | ground | |
| 8 | SCL | bidirectional | |
| 9 | SDA | bidirectional | |
| 10 | INT | bidirectional |
Schematic symbol and footprint
Footprint: Adafruit TSC2007 (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
