ADA2926 · AdafruitActive
Adafruit product #2926.
| Part number | ADA2926 |
|---|---|
| Manufacturer | Adafruit |
| Category | Interface & Expansion › Breakouts & Adapters |
| Pins | 88 |
Assembled Terminal Block Breakout FeatherWing for all Feathers pinout
| Pin | Name | Type | Description |
|---|---|---|---|
| 1 | 3V | power | |
| 2 | 3V | power | |
| 3 | GND | ground | |
| 4 | GND | ground | |
| 5 | VBAT | power | |
| 6 | ENABLE | bidirectional | |
| 7 | USB | power | |
| 8 | N | bidirectional | |
| 9 | M | bidirectional | |
| 10 | L | bidirectional | |
| 11 | K | bidirectional | |
| 12 | J | bidirectional | |
| 13 | I | bidirectional | |
| 14 | H | bidirectional | |
| 15 | SCL | bidirectional | |
| 16 | SDA | bidirectional | |
| 17 | VBAT | power | |
| 18 | ENABLE | bidirectional | |
| 19 | USB | power | |
| 20 | N | bidirectional | |
| 21 | M | bidirectional | |
| 22 | L | bidirectional | |
| 23 | K | bidirectional | |
| 24 | J | bidirectional | |
| 25 | I | bidirectional | |
| 26 | H | bidirectional | |
| 27 | SCL | bidirectional | |
| 28 | SDA | bidirectional | |
| 29 | VBAT | power | |
| 30 | ENABLE | bidirectional | |
| 31 | USB | power | |
| 32 | N | bidirectional | |
| 33 | M | bidirectional | |
| 34 | L | bidirectional | |
| 35 | K | bidirectional | |
| 36 | J | bidirectional | |
| 37 | I | bidirectional | |
| 38 | H | bidirectional | |
| 39 | SCL | bidirectional | |
| 40 | SDA | bidirectional | |
| 41 | RESET | bidirectional | |
| 42 | 3V | power | |
| 43 | AREF | bidirectional | |
| 44 | GND | ground | |
| 45 | A | bidirectional | |
| 46 | B | bidirectional | |
| 47 | C | bidirectional | |
| 48 | D | bidirectional | |
| 49 | E | bidirectional | |
| 50 | F | bidirectional | |
| 51 | SCK | bidirectional | |
| 52 | MOSI | bidirectional | |
| 53 | MISO | bidirectional | |
| 54 | RX | bidirectional | |
| 55 | TX | bidirectional | |
| 56 | G | bidirectional | |
| 57 | RESET | bidirectional | |
| 58 | 3V | power | |
| 59 | AREF | bidirectional | |
| 60 | GND | ground | |
| 61 | A | bidirectional | |
| 62 | B | bidirectional | |
| 63 | C | bidirectional | |
| 64 | D | bidirectional | |
| 65 | E | bidirectional | |
| 66 | F | bidirectional | |
| 67 | SCK | bidirectional | |
| 68 | MOSI | bidirectional | |
| 69 | MISO | bidirectional | |
| 70 | RX | bidirectional | |
| 71 | TX | bidirectional | |
| 72 | G | bidirectional | |
| 73 | RESET | bidirectional | |
| 74 | 3V | power | |
| 75 | AREF | bidirectional | |
| 76 | GND | ground | |
| 77 | A | bidirectional | |
| 78 | B | bidirectional | |
| 79 | C | bidirectional | |
| 80 | D | bidirectional | |
| 81 | E | bidirectional | |
| 82 | F | bidirectional | |
| 83 | SCK | bidirectional | |
| 84 | MOSI | bidirectional | |
| 85 | MISO | bidirectional | |
| 86 | RX | bidirectional | |
| 87 | TX | bidirectional | |
| 88 | G | bidirectional |
Schematic symbol and footprint
Schematic symbol
Footprint: Adafruit Terminal Breakout FeatherWing (header pads) — to scale, pad 1 in yellow (mm). Check against the datasheet before ordering PCBs.
Datasheet
Where to buy
Stock and prices from the suppliers, checked 2026-10-08; excluding tax and shipping.
